Main Performance

• Dual-Head Operation: One machine with two heads, capable of independent operation, truly meeting the production requirements for two different yarn types.

• Large-Capacity Bobbin Output: Diameter of 500–600 mm, improving production efficiency.

• Modular Machine Design: Bobbin changing and sliver coiling sections are independent, facilitating transport and installation.

• Uster UQA Self-Regulating Carding System: Equipped with eddy-current online monitoring and pneumatic yarn start technology.

• Advanced Automatic Bobbin Change & Sliver Break Technology: Achieves fully automatic bobbin replacement, increasing production efficiency by approximately 15%.

• Touchscreen HMI: Allows operators to adjust sliver weight and other process parameters easily.

• Stable Transmission: Multi-wedge belt, synchronous belt, and V-belt drive ensure smooth operation with low noise.

• High-Quality Coiling System: Alloy aluminum-coated stainless steel coiler with integrated full-length fiber guide tube; coiler base plate coated with stainless steel; special anti-static surface treatment effectively prevents fiber fly and neps caused by static.

• Front-Positioned Air Duct Cleaning System: Efficiently removes fiber fly, short fibers, and impurities from the drafting zone; pressure bars stay clean, and rubber rollers dissipate heat effectively.

• Independent Suction Dust Removal Cotton Box: Equipped with automatic cotton scraping; fan uses static pressure control and variable-frequency speed regulation, saving energy and reducing consumption.

• Ethernet-Ready Main Machine: Integrated with industrial IoT platform for intelligent connectivity; machine status, production, efficiency, energy consumption, and faults can be monitored or adjusted via computer or mobile devices, enabling remote diagnostics and maintenance.

---

Key Technical Features

• Uster UQA Self-Regulating Carding System with eddy-current online monitoring and pneumatic yarn start technology.
